Introducing the T86 & S86 Loaders!
The Bobcat® T86 and S86 are the most powerful compact loaders we’ve ever built, delivering more usable engine and hydraulic horsepower than ever before. We’ve boosted the horsepower for the T86 compact track loader and S86 skid-steer loader while optimizing machine weight. The result is greater lifting capabilities, impressive breakout forces and leading maneuverability for fast cycle times. Compare the weight-to-horsepower ratio of the T86 and S86 to other machines in their class size and you’ll understand why these machines deliver the all-around performance you expect for today’s most demanding jobs.
From a bucketful of dense material to a truck filled with loaded pallets, the ability to lift more, carry more and reach farther provides a true measure of loader productivity. With added horsepower and improved lifting capability throughout the loaders’ range of motion, the T86 and S86 are truly revolutionary.
Key Specs:
| S86 | T86 | |
|---|---|---|
| ROC - 50% of Tip Load | 3,400 lb. | 5,429 lb. |
| Height to Bucket Hinge Pin | 132 in. | 132 in. |
| Operating Weight | 9,728 lb. | 12,393 lb. |
| Width with Bucket | 74 in. | 80 in. |
| Travel Speed - Low Range | 6.9 mph | 5.5 mph |
| Travel Speed - High Range | 12.3 mph | 10.7 mph |
| Horsepower | 105 hp | 105 hp |
Hydraulic Specs:
| S86 | T86 | |
|---|---|---|
| Standard Flow | 23.5 GPM | 23.5 GPM |
| High Flow | 36.6 GPM | 36.6 GPM |
| Super Flow | 42 GPM | 42 GPM |
| Hydraulic System Pressure - Standard & High Flow | 3,500 psi | 3,500 psi |
| Hydraulic System Pressure - Super Flow | 4,061 psi | 4,061 psi |
Performance to Make you More Precise and Productive
Designed to boost productivity, Premium Power Performance is an optional power management system that distributes power more efficiently. Premium Power Performance improves engine-to-workgroup efficiency, distributing more power where and when it’s needed during multi-tasking operations. The innovative power management system makes these R-Series machines highly controllable and extremely efficient. Smoother, faster control, with maximum power where and when you need it most means more heavy-duty work done per day.
Built for the Long Haul
Better, more reliable cooling is essential as operators demand compact equipment that can run longer and do bigger, more difficult jobs. The R-Series cooling system is completely redesigned with a larger, high-capacity radiator and fan for optimal operation and maximum uptime. Larger auxiliary hydraulic hoses and tube lines deliver more efficient flow and support cooler operating temperatures. R-Series loaders also make routine maintenance easy and support operator uptime with features including: a reversible fan, maintenance-free chaincase, a machine protection system that safeguards against damage to the engine and hydraulics, simplified emissions, protected hoses and quick couplers, and real-time self-diagnostics.
Versatility to Fit More Tasks
Only the Bobcat T86 and S86 deliver three hydraulic flow options - standard, high and super flow - in one machine, setting a new industry benchmark in performance and attachment versatility. Each component, including the engine, pumps and hydraulic system, is engineered to deliver maximum hydraulic performance so you can work quicker, lift more and take your productivity to new heights.
Premium Comfort and Ease of Use
The R-Series T86 and S86 carry on the Bobcat tradition of providing a comfortable, well-designed operator experience for all-day productivity. The roomy cab offers a sealed and pressurized environment that repels dust and dirt, isolates the operator from noise, and enhances the efficiency of heating and air conditioning. Comfort options include a roomy cab, a heated air-ride seat, automatic heat and air conditioning, ergonomic controls and innovative displays to keep you productive on long, challenging days. The easy-to-read cab display, a standard feature in R-Series loaders, provides full-featured machine interaction and monitoring capabilities.
